Nanolux DE1000W Complete Grow Full Fixture 208V-240V + Grow Lamp

ECO Farm

Collections: ECO Farm Grow Lights

Type: Unknown Type

Product Description:

208-240V Nanolux NCCS ready 1000w Double Ended (DE) complete fixtures are the most state-of-the-art grow lights ever to be released by Nanolux. Nanolux DE fixtures, when paired with the RTU (remote terminal unit) and DTU (brain modem) can be controlled completely via software. Use the NCCS to control up to 999 fixtures on one DTU. This Nanolux is the new App Version which runs on Nanolux's 2.0 software application.

The Nanolux DE complete fixture has increased the standard 1150W to 1200W allowing the fixture to produce a class leading luminous flux of 160,300lm. The upgraded components, like ceramic bulb receptacles, make the Nanolux DE fixture the safest on the market. The Nanolux DE fixture is NCCS ready, meaning you will be able to control it wirelessly on your computer through the Nanolux Cloud Control System. Like all of our ballasts the DE comes with Random Start, Soft Start, and Soft Dimming capabilities. The traditional square hood is designed to work on a 5' on center application in conjunction with other DE fixtures. This is the secret to DE lighting. When used with the traditional square reflector, the DE will create an interlacing light pattern with the other lights. This interlacing allows for deeper light penetration. This results in denser fruit and flower sets all over the plant increasing yield by as much as 10%. All Nanolux ballasts are ETL listed meeting product safety standards.

Product Features:

  • NCCS ready smart ballast technology
  • Heavy duty die cast bridge will not rust like formed
  • Lowest profile fixture on the market allowing for max plant height
  • Ballast and reflector can be separated for Remote DE ballast use
  • Class leading lowest operating temperature
  • Redesigned and upgraded reflector that provides 8% better light uniformity than the competition
  • Best in class 97% reflective German aluminum reflector
  • Exclusive ceramic industrial grade receptacles
  • The only wireless controlled DE on the market – no need for relays/light control panels, or timers
  • Plug and Play installation
  • Random Start, Soft Start and Soft Dim technology
  • 6 phase dimming (600-1200 watts)
  • Includes Nanolux DE bulb
  • Compatible with other industry DE Bulbs
  • Designed for a 5' on center growing grid when used with the traditional square reflector
  • Slow Start, open circuit and low voltage protection
  • 3 year warranty
  • Product Specifications:

  • Input Voltage: 208-240V, (other voltage models available in 277V) ( voltage models in 347 & 480V are special special order)
  • Output Voltage: 600-1200 watts (6 settings)
  • Amperage Draw: 5.2A/240V @ 1200W
  • Input Frequency: 50/60Hz
  • Operational Frequency: >85kHz
  • THD: <10%
  • PF: >0.99
  • CF: <1.7
  • Ta = 30c (86F)
  • Tc = 65c (149F)
  • Ballast and Fixture weight: 11.7lbs
  • Ballast and Fixture Dimension: 26.2"x12"x6.1"
  • Bulb: MaxPar 2100µmol DE Bulb
